Rainsub 60M 230 V
Rainsub 60M 230 V
Product number:
18893
Rainsub 60M 230 V
Product number:
18893
- Multi-stage, smooth-running submersible motor pump
- Max. flow rate: 5,7 m³/h
- Max. head: 57,0 m
- Input power P1: 1.250 W
- Output power P2: 750 W
- Pressure outlet: 1" Internal thread
Model
- Multi-stage, low-noise submersible motor pump
- Drinking water replenishment possible via replenishment modules, thanks to connection nozzle
- Double mechanical seal with oil chamber ensures reliable sealing between hydraulic section and motor
- Excellent hydraulic performance
- Plug & Play – single-phase version pre-wired and ready to connect
- Slim design makes it suitable for a wide range of applications
- Stable stand thanks to pump base
- Optionally with float switch (Type MA) for connection to a floating intake
- Pump housing, impellers, and suction nozzle made of stainless steel 1.4301, shaft made of stainless steel 1.4021
- Includes 20 m power cable (H07 RNF), plug, and integrated start capacitor
Application
- water supply
- rainwater harvesting
- washing facilities
- irrigation
- pressure boosting
- for clear to slightly contaminated water without aggressive and abrasive components
Scope of delivery
- 20 m power cable H07 RNF, plug and built-in starting capacitor
| Frequency: | 50 |
|---|---|
| Head up to [m]: | 57.0 |
| Max. temperature [°C]: | 35 |
| Nominal current [A]: | 5.7, 6.0 |
| Packing (WxHxL): | 200 x 200 x 750 |
| Power P1 [W]: | 1250 |
| Speed [U/min]: | 2850 |
| Voltage [V]: | 230 |
| C [µF]: | 25 |
