Water isolation station
Water isolation station
Product number:
18860
Water isolation station
Product number:
18860
- Flow rate Qmax: 5.2 m³/h
- Max. head: 52.0 m
- Input power P1: 1.350 W
- Refill volume: 5.0 l
Model
- self-priming, maintenance-free, multi-stage, horizontal centrifugal pump
- drinking-water connector 3/4“, external thread, right-hand side; discharge connector 1“, internal thread, emergency overflow, optionally left-hand or right-hand side
- automatic control Kit 5 Optimatic: - When one of the consumers gets opened, the pump is automatically switched on. - When all the consumers are closed, the pump is automatically switched off
- suction and discharge case made of α-brass
- pump case and impellers consist of stainless steel 1.4301
- shaft made of stainless steel 1.4401
- end face mechanical seal consisting of carbon + ceramic
- guide wheels made of special (Noryl®)
- motor case made of light metal L-2521
- o-ring made of NBR
- case Kit-05 Optimatic, PPO recyclable
Application
- irrigation
- pressure boost
- for clear water without aggressive components
Scope of delivery
- plug-ready
| Application: | Supply |
|---|---|
| Frequency: | 50 |
| Head up to [m]: | 52.0 |
| Installation location: | inside buildings |
| Max. flow rate [m³/h]: | 5.2 |
| Max. temperature [°C]: | 40 |
| Nominal current [A]: | 6.1 |
| Power P1 [W]: | 1.350 |
| Power P2 [W]: | 1050 |
| Pumped medium: | clear water, rainwater |
| Speed [U/min]: | 2850 |
| Voltage [V]: | 230 |
| C [µF]: | 25 |
