Lademax
Lademax
Product number:
19096
Lademax
Product number:
19096
Model
- compact and corrosion-resistant sewage water submersible pump
- including floating tap and check valve
- fixed vertical float switch
- with built-in compressor connecting cable, 10 m long
Application
- feeder pump for rainwater modules with long
- suction lines and bigger suction heights
- supply of service water
Scope of delivery
- 10 meter connection cable
| Application: | Supply |
|---|---|
| Features: | mit Kompaktschwimmer |
| Frequency: | 50 |
| Head up to [m]: | 11.0 |
| Installation location: | inside buildings |
| Max. flow rate [m³/h]: | 13.5 |
| Max. temperature [°C]: | 40 |
| Nominal current [A]: | 3.5 |
| Packing (WxHxL): | 300 x 480 x 300 |
| Power P1 [W]: | 780 |
| Pumped medium: | clear water, rainwater |
| Speed [U/min]: | 2850 |
| Voltage [V]: | 230 |
