Raincenter Basic 25
Raincenter Basic 25
Product number:
19080
Raincenter Basic 25
Product number:
19080
Model
- fully automatic electronic control of the entire installation
- integrated domestic water works CPS 20-5 with automatic control ZP Control 05 Basic
- house-internal drinking water replenishing on demand directly to the pump by-passing the tank
Application
- compact central unit for automatic control and water supplies from rainwater utilization plants
- multi-apartment houses and similar objects
- clear water without aggressive and abrasive components
Scope of delivery
- filling level transducer with cable, 20 m long
- wall mounting set including vibration-damping equipment
| Application: | Supply |
|---|---|
| Frequency: | 50 |
| Head up to [m]: | 52.0 |
| Installation location: | inside buildings |
| Max. temperature [°C]: | 40 |
| Nominal current [A]: | 5.2, 6.1 |
| Packing (WxHxL): | 710 x 370 x 700 |
| Power P1 [W]: | 1350 |
| Pumped medium: | clear water, rainwater |
| Speed [U/min]: | 2850 |
| Voltage [V]: | 230 |
| C [µF]: | 25 |
