ZPS control unit for single or double pump systems
ZPS control unit for single or double pump systems
Product number:
12510
ZPS control unit for single or double pump systems
Product number:
12510
Model
- polycarbonate switch box for wall mounting
- displaying of operation modes via clear text display and signal lights
- automatic operation of one three-phase or mono-phase pump
- programmable starting delay and follow-up time
- visual and audible fault signal with potential-free outputs
- level control by means of dynamic pressure method, float switches or 4 - 20 mA interface for external sensor
- displaying of operating hours, power consumption and maintenance interval
- fault memory for last 64 faults
Application
- automatic pump control of one (ZPS 1) or 2 pumps (ZPS2)
| Nominal current [A]: | 0.3-14 |
|---|---|
| Packing (WxHxL): | 230 x 260 x 380 |
