CPS 20-5M SM GG 230V
CPS 20-5M SM GG 230V
Product number:
18564
CPS 20-5M SM GG 230V
Product number:
18564
- Self-priming, horizontal, multistage centrifugal pump with stainless steel impellers and on/off switch
- Max. flow rate: 5,4 m³/h
- Max. head: 52,0 m
- Input power P1: 1.350 W
- Output power P2: 1.050 W
- Pressure outlet: 1" Internal thread
Model
- Self-priming, maintenance-free, multi-stage, horizontal centrifugal pump
- High efficiency
- Suction and pressure ports, internal thread (1" - 1¼")
- CPS SM with on/off switch
- CPS GG/SM: Suction and pressure housing made of gray cast iron
- CPS B: Suction and pressure housing made of dezincification-resistant α-brass Impellers made of glass-fiber-reinforced Noryl®
Applications
- Household water supply
- Rainwater harvesting
- Pressure boosting
- Irrigation for clear water without aggressive and abrasive components
Scope of delivery
- Pre-wired, incl. 1.5 meters of power cable H07 RNF with plug
| Application: | Supply |
|---|---|
| Features: | Ein- / Aus- Schalter |
| Frequency: | 50 |
| Head up to [m]: | 52.0 |
| Installation location: | inside buildings |
| Max. flow rate [m³/h]: | 5.4 |
| Max. temperature [°C]: | 40 |
| Nominal current [A]: | 5.8 |
| Packing (WxHxL): | 190 x 240 x 450 |
| Power P1 [W]: | 1350 |
| Pumped medium: | clear water, rainwater |
| Speed [U/min]: | 2850 |
| Voltage [V]: | 230 |
| C [µF]: | 25 |
