CPS 35-4 GG 400V
CPS 35-4 GG 400V
Product number:
18612
CPS 35-4 GG 400V
Product number:
18612
- Self-priming, horizontal, multistage centrifugal pump with stainless steel impellers
- Max. flow rate: 10,2 m³/h
- Max. head: 50,0 m
- Input power P1: 1.800 W
- Output power P2: 1.400 W
- Pressure outlet: 1 1/4" internal thread
Model
- Self-priming, maintenance-free, multi-stage, horizontal centrifugal pump
- High efficiency Suction and pressure ports, internal thread (1" - 1¼")
- CPS SM with on/off switch
- CPS GG/SM: Suction and pressure housing made of gray cast iron
- CPS B: Suction and pressure housing made of dezincification-resistant α-brass Impellers made of glass-fiber-reinforced Noryl®
Applications
- Household water supply
- Rainwater harvesting
- Pressure boosting
- Irrigation for clear water without aggressive and abrasive components
Scope of delivery
- Pre-wired, incl. 1.5 meters of power cable H07 RNF with plug
| Application: | Supply |
|---|---|
| Frequency: | 50 |
| Head up to [m]: | 50.0 |
| Installation location: | inside buildings |
| Max. flow rate [m³/h]: | 10.2 |
| Max. temperature [°C]: | 40 |
| Nominal current [A]: | 5.6/3.2 |
| Packing (WxHxL): | 220 x 280 x 450 |
| Power P1 [W]: | 1800 |
| Pumped medium: | clear water, rainwater |
| Speed [U/min]: | 2850 |
| Voltage [V]: | 3~230/3~400 |
