SWH 500 (simplex and duplex version)
SWH 500 (simplex and duplex version)
Product number:
11544
SWH 500 (simplex and duplex version)
Product number:
11544
- Waste water lifting unit with built-in stainless steel submersible pump(s) E-ZW
- Max. flow rate: 7,5 m³/h
- Max. head: 7,5 m
- Input power P1: 380 W
- Output power P2: 210 W
- Solids handling: 10 mm
- Pressure outlet: 1 1/4" internal thread
Model
- polyethylene container with 135 litres capacity and up to 75 litres switching volume
- with submersible waste water pump E-ZW with float switch
- pump housing, motor housing, shaft and suction strainer made of stainless steel, impeller made of polyamide
- pressure outlet 1 ¼“ FPT
- operation temperature 40°C (short-term 90°C)
- protection grade IP 57 - temporary submersible
Application
- pumping of domestic waste water from washing machines, showers, washbasins etc.
- above-ground installation in frost-free rooms below the backflow level
Scope of delivery
- pre-assembled ready for connection with 3 m power cable and plug
- pressure outlet incl. non-return valve(s) and gate valve
- incl. float switch
| Application: | Disposal |
|---|---|
| Features: | mit Schwimmerschalter |
| Frequency: | 50 |
| Installation location: | inside buildings |
| Max. flow rate [m³/h]: | 7.5 |
| Max. temperature [°C]: | 40 (kurzzeitig 90) |
| Nominal current [A]: | 1.8 |
| Packing (WxHxL): | 580 x 600 x 790 |
| Power P1 [W]: | 380 |
| Power P2 [W]: | 210 |
| Pumped medium: | waste water |
| Solids handling [mm]: | 5 |
| Speed [U/min]: | 2800 |
| Voltage [V]: | 230 |
| C [µF]: | 10 |
