UFB 200/30
UFB 200/30
Product number:
11491
UFB 200/30
Product number:
11491
- Underfloor box
- Max. flow rate: 7,0 m³/h
- Max. head: 7,5 m
- Input power P1: 300 W
- Output power P2: 130 W
- Solids handling: 10 mm
- Pressure outlet: 1 1/4" external thread
Model
Application
- polyethylene container with 35 litres capacity and up to 20 litres switching volume
- built-in waste water pump ZPK with float switch
- connection for air vent and cable gland DN 50 (HT)
- inlet connection piece DN 50 is included - installable by drilling a hole in the container
- pressure outlet 1 ¼“ with integrated non-return valve
- operation temperature 40°C (short-term 90°C)
- protection grade IP 68 - fully submersible
Application
- pumping of domestic waste water from washing machines, showers, washbasins etc.
- below-ground installation in frost-free rooms below the backflow level
Scope of delivery
- pre-assembled ready for connection with 10 m power cable and plug
- accessible plastic grade, siphon, sand-trap
- inlet connection piece DN 50
- extended top section and closed cover plate available as accessories
| Application: | Disposal |
|---|---|
| Features: | mit Schwimmerschalter |
| Frequency: | 50 |
| Head up to [m]: | 7.0 |
| Installation location: | inside buildings |
| Max. flow rate [m³/h]: | 7.5 |
| Max. temperature [°C]: | 40 (kurzzeitig 90) |
| Nominal current [A]: | 1.3 |
| Packing (WxHxL): | 350 x 425 x 500 |
| Power P1 [W]: | 300 |
| Power P2 [W]: | 130 |
| Pumped medium: | waste water |
| Solids handling [mm]: | 5 |
| Speed [U/min]: | 2800 |
| Voltage [V]: | 230 |
| C [µF]: | 10 |
