Kompaktboy SE 71 Duplex
Kompaktboy SE 71 Duplex
Product number:
17462
Kompaktboy SE 71 Duplex
Product number:
17462
- Double sewage lifting unit with cutter pumps
- Max. flow rate: 17,0 m³/h
- Max. head: 22,0 m
- Input power P1: 2.100 W
- Output power P2: 1.700 W
- Pressure outlet: DN 50
Model
- polyethylene container with 150 litres capacity and up to 80 litres switching volume
- two built-up grinder pumps with robust, adjustable cutting system made of corrosion-resistant special alloy
- two mechanical seals with intermediate oil chamber
- pressure outlet flange DN 50 with flanged connecting bend and non-return ball valve 1 1/4" FPT
- inlets: 3 x lateral DN 100 and 1 x top DN 100/150
- additional connections 1 ½“ for manual diaphragm pump
- air vent DN 70 (Ø 75mm)
- operation temperature max. 55°C
- operating mode S3 - 25%
- protection grade IP 68 - fully submersible
Application
- pumping of domestic sewage from single-family houses and apartment buildings for greater heads or long pressure pipes
- above-ground installation in frost-free rooms below the backflow level
Scope of delivery
- pre-assembled lifting unit with 3,5 m connection cable to the motor and 3,5 m pneumatic tube to the control
- 2 x 90° pump connecting bend DN 50
- 2 x non-return ball valve 1 1/4" FPT
- stainless steel Y-pipe DN 50/50/50 with pressure outlet flange DN 50
- flexible connection with tension clamps for ventilation pipe
- incl. ZPS2: comfortable, pneumatic level control with microcontroller, LCD plain text display for filling level, maintenance, operating hours, fault message and alarm signal in switchbox for indoor installation
| Application: | Disposal |
|---|---|
| Features: | mit pneumatischer Pumpensteuerung für Doppelpumpanlagen |
| Frequency: | 50 |
| Head up to [m]: | 22.0 |
| Installation location: | inside buildings |
| Max. flow rate [m³/h]: | 17.0 |
| Nominal current [A]: | 3.7 |
| Packing (WxHxL): | 780 x 1070 x 1180 |
| Power P1 [W]: | 1700, 2100 |
| Pumped medium: | sewage containing faeces, waste water |
| Speed [U/min]: | 2800 |
| Voltage [V]: | 400 |
