Boy Simplex
Boy Simplex
Product number:
10527
Boy Simplex
Product number:
10527
- Single sewage lifting unit with vortex pump
- Max. flow rate: 40,0 m³/h
- Max. head: 7,0 m
- Input power P1: 1.900 W
- Output power P2: 1.500 W
- Solids handling: 50 mm
- Pressure outlet: DN 100 (DN 80 optional)
Model
- polyethylene container with 140 litres capacity and up to 70 litres switching volume
- vortex pump with high efficiency
- mechanical seal and shaft seal with intermediate oil chamber
- inlets: 2 x DN 100
- additional connections 1 ½“ for manual diaphragm pump
- air vent DN 70 (Ø 75mm)
- operation temperature max. 55°C
- operating mode S3 - 25%
- protection grade IP 68 - fully submersible
Application
- pumping of domestic sewage from basement apartments, single-family houses or apartment buildings
- above-ground installation in frost-free rooms below the backflow level
Scope of delivery
- pre-assembled lifting unit with 3,5 m connection cable to the motor and 3,5 m pneumatic tube to the control
- incl. non-return valves DN 100 (DN 80 optional)
- connection flange piece DN 100 for pressure pipe (DN 80 optional) flexible connection with tension clamps for pressure pipe and ventilation pipe
- incl. ZPS1: comfortable, pneumatic level control with microcontroller, LCD plain text display for filling level, maintenance, operating hours, fault message and alarm signal in switchbox for indoor installation
| Application: | Disposal |
|---|---|
| Features: | mit pneumatischer Pumpensteuerung für Einzelpumpen |
| Frequency: | 50 |
| Head up to [m]: | 7.0 |
| Installation location: | inside buildings |
| Max. flow rate [m³/h]: | 40.0 |
| Max. temperature [°C]: | 55 |
| Nominal current [A]: | 3.3 |
| Packing (WxHxL): | 580 x 600 x 790 |
| Power P1 [W]: | 1900 |
| Power P2 [W]: | 1500 |
| Pumped medium: | sewage containing faeces, waste water |
| Speed [U/min]: | 1400 |
| Voltage [V]: | 400 |
