Solida 262 / 635 - impeller
Solida 262 / 635 - impeller
Product number:
19024
Solida 262 / 635 - impeller
Product number:
19024
- Submersible waste water pump made of stainless steel and grey cast iron
- Max. flow rate: 24,0 m³/h
- Max. head: 10,5 m
- Input power P1: 830 W
- Output power P2: 500 W
- Solids handling: 32 mm
- Pressure outlet: 2"
Model
- submersible motor pump with conduit impeller
- float switch for automatic operation (version A) and dry-running protection
- double end face mechanical seal in oil chamber
- immersion depth 20 m
Application
- drainage
- agriculture
- suited for contaminated water with particulates, maximum grain size 32 mm
Scope of delivery
- including cable H 07 RN-F, 10 m long and plug (230 V only)
| Application: | Disposal |
|---|---|
| Features: | mit Schwimmerschalter |
| Frequency: | 50 |
| Installation location: | outside buildings, portable, pump sump |
| Max. flow rate [m³/h]: | 4.2, 24.0 |
| Nominal current [A]: | 10.5 |
| Packing (WxHxL): | 180 x 245 x 465 |
| Power P2 [W]: | 550 |
| Pumped medium: | clear water, rainwater, waste water |
| Solids handling [mm]: | 32, 45 |
| Speed [U/min]: | 2800 |
| Voltage [V]: | 230 |
| C [µF]: | 16 |
