Drain Inox 90 MA
Drain Inox 90 MA
Product number:
19010
Drain Inox 90 MA
Product number:
19010
- Stainless steel submersible pump
- Max. flow rate: 15,0 m³/h
- Max. head: 13,0 m
- Input power P1: 550 W
- Output power P2: 350 W
- Solids handling: 10 mm
- Pressure outlet: 1 1/4" internal thread
Model
- jacket-cooled submersible motor pump made of stainless steel 1.4301
- float switch (A) for automatic operation and dry-running protection
Application
- basement drainage
- rainwater
- manufacturing / industry
- agriculture
- suited for clear to slightly contaminated water with suspended solids (no stones) up to grain size of 10 mm, not for faeces-containing waste water.
Scpoe of delivery
- Including cable H 07 RN-F, 10 m long
| Application: | Disposal |
|---|---|
| Features: | mit Schwimmerschalter |
| Frequency: | 50 |
| Head up to [m]: | 13.0, 15.0 |
| Installation location: | inside buildings, outside buildings, portable, pump sump |
| Max. temperature [°C]: | 35 |
| Nominal current [A]: | 4.4 |
| Packing (WxHxL): | 390 x 260 x 240 |
| Power P2 [W]: | 550 |
| Pumped medium: | clear water, rainwater, waste water |
| Speed [U/min]: | 2800 |
| Voltage [V]: | 230 |
| C [µF]: | 10 |
