ZPG 71.1 W
ZPG 71.1 W
Product number:
17836
ZPG 71.1 W
Product number:
17836
- Submersible waste water pump made of grey cast iron
- Max. flow rate: 43,0 m³/h
- Max. head: 19,0 m
- Input power P1: 2.200 W
- Output power P2: 1.600 W
- Solids handling: 40 mm
- Pressure outet: DN 50
Model
- submersible waste water pump made of cast iron for portable and stationary (coupling system) purposes
- pump housing, motor housing and impeller made of cast iron, shaft made of stainless steel
- double bidirectional mechanical seals with intermediate oil chamber
- pressure outlet DN 50
- lateral cable gland with strain relief and kink protection
- protection grade IP 68 – fully submersible
Application
- pumping of waste water with solid ingredients
- pumping of rainwater and surface water
- portable pump for emergency drainage and drainage of manholes
Scope of delivery
- version M (mono-phase 230 V) with 10 m power cable, control unit with motor protection, capacitor and plug
- all pumps without stand feet and outlet bend
- optional coupling system (see accessories)
| Features: | ohne Schwimmerschalter |
|---|---|
| Frequency: | 50 |
| Head up to [m]: | 19.0 |
| Max. flow rate [m³/h]: | 43.0 |
| Max. temperature [°C]: | 40 |
| Nominal current [A]: | 10.5 |
| Packing (WxHxL): | 330 x 635 x 330 |
| Power P1 [W]: | 2200 |
| Power P2 [W]: | 1600 |
| Speed [U/min]: | 2800 |
| Voltage [V]: | 1~230 |
